Hydmech V18APC 60 CNC Vertical Band Saw

Capacity – 558 x 457mm

Manufactured in Canada, the Hydmech V18APC60 CNC vertical band saw is ideal for cutting larger beams, structural steel, and bundles of square tubing.

This CNC vertical bandsaw can mitre both left and right to 60° even when being used in automatic mode. The mitre angle is a programmed function.

A 3 degree fixed canted head allows for more efficient cutting and improved blade life.

The saw includes four full stroking hydraulic vices: the shuttle feed vice, vices either side of the blade and a squaring vice. The squaring vice is very useful for ensuring accuracy on long heavy lengths of material.

It has a cast-iron feed shuttle with 1000mm travel in a single stroke and automatic multi indexing if cutting length requires. It has a cutting chamber that separates the material from the cut part.

The V-18APC uses a Mitsubishi PLC (Programmable Logic Controller) which allows up programming for up to 99 jobs with 5 in a queue.

Standard equipment includes chip conveyor, laser line and low voltage lamp as well as variable vice pressure and on-demand hydraulic system to conserve energy.
